ULTRASOUND WATT METER
What makes the UW7 Unique?
A heavy cast frame firmly supports the rugged straight bar load cell. It provides for faster technician on-site visits and protects the load cell from damage during transit.
Support Ring Sets provide precise sound head centering and alignment for accurate readings.
Only requires 375ml of degassed water - greatly reducing degassed water requirements.
The UW7 provides accurate verifying and calibrating readout of therapeutic ultrasound devices.
- Special temperature compensated load cell design.
- 0.10 watt to 30 watt power measurement range.
- Fast auto zeroing button
- Extremely fast 2 second readout stabilization.
- Measures pulsed or continuous power.
- 2.65"(6.7cm) diameter sound head maximum
- High contrast back lit display.
- Selectable, readout in watts or grams.
- 120V or 240VAC 50-60 Hz standard.
- Accuracy = ± 3% + one count reading.
- Includes soft pack protective carrying case.
- CE APPROVED
SPECIFICATIONS
Unit Dimensions - 8.5" W, 12"L, 7.25" H
Unit Weight - 8.25 lbs (3.74kg)
Readout - Watts or Grams
Function Check Weights - 75g or 200g
PRODUCT FEATURES
Optional RS-232 cable
Optional USB cable
Optional high capacity lithium ion, 36 hour battery
